Tension Controller
– Model CTD1200 for OPB/C, HB/C actuators (max 1.5 A output)
– Model CTD3200 for larger actuators (max 3.0 A output)
– Output voltage to brakes can be monitored

Tension Range
– Determined upon each application

Speed Range
– Max 500 (m/min), but depends on tension ranges and application details

Compatible package sizes and core sizes
– Max package diameter is 999mm
– Various lineup of core chuck available to meet customer requirements

Tension Actuator
– Standard actuator lineup consisting of OPB electromagnetic particle brakes, OPC electromagnetic particle clutches, HB electromagnetic hysteresis brakes, HC electromagnetic hysteresis clutch

Creel Framework
– Standard and custom configurations available

Fiber Guiding
– Pin combs, eyelet guides, and yarn guide rollers

Other
– Stability factor can be adjusted in cases where diameter measurement fluctuation occurs (products with uneven distribution on reel, etc.)

Operator Interface
– CTS1160 type digital setting unit
